Abstract This thesis presents the control problems of irrigation network with communication constraints and a multi-layer approach to solve these problems in a distributed manner. Detailed discussions of each layer with analytical and simulation results are described throughout several chapters. They emphasize the potential interest of the multi-layer approach, more precisely its efficiency and reliability for supervision, multi-objective optimization and distributed cooperative control of complex water transport systems. The first layer to be considered is the hydraulic network composed of free-surface channels, hydraulic structures and mesh subnetwork of pressurized pipes.

By coupling the Saint-Venant equations for describing the physics of free-surface fluid and the Lattice Boltzmann method for the fluid simulation, a discrete-time nonlinear model is obtained for the channels. The hydraulic structures are usually treated as internal boundaries of reaches and modeled by algebraic relationships between the flow and pressure variables. To enable the exchange of the information among the control system’s components, a communication network is considered in the second layer. Solving challenging problems of heterogeneous devices and communication issues (e., network delay, packet loss, energy consumption) is investigated in this thesis by introducing a hybrid network architecture and a dynamic routing design based on Quality of Service (QoS) requirements of control applications.

For network routing, a weighted composition of some standard metrics is proposed so that the routing protocol using the composite metric achieves convergence, loop-freeness and path- optimality properties. Through extensive simulation scenarios, different network performance criteria are evaluated. The comparison of simulation results can validate the interest of this composition approach for dynamic routing. Finally, the third layer introduces an optimal reactive control system developed for the regulatory control of large-scale irrigation channels under a Distributed Cooperative Model Predictive Control (DCMPC) framework.

This part discusses different control implementation strategies (e., centralized, decentralized, and distributed strategies) and how the cooperative communication among local MPC controllers can be included to improve the performance of the overall system. Managing the divergent (or outdated) information exchanged among controllers is considered in this thesis as a consensus problem and solved by using an asynchronous consensus protocol. Based on the multi-agent system paradigm, this approach to distributed control provides a solution guaranteeing that all controllers have a consistent view of some data values needed for action computation. A particular benchmark of an irrigation channel is viii | investigated in simulations.

The comparison of simulation results validates the benefits of the distributed cooperative control approach over other control strategies. Keywords - irrigation network, Saint-Venant (SV) equations, Lattice Boltzmann (LB) method, Networked Control System (NCS), Low power and Lossy Network (LLN), hybrid architecture, dynamic routing, Routing Protocol for Low power and lossy network (RPL), composite metric, distributed control, cooperative control, asynchronous consensus, Multi-Agent System (MAS). Résumé Cette thèse présente une contribution sur les problèmes de contrôle de réseaux d’irrigations en ten- ant compte des contraintes de communication grâce à une approche multi-couches d’intelligence distribuée. Les analyses détaillées de chaque couche avec les résultats analytiques et les simula- tions seront décrites dans les différents chapitres.

Ils mettent l’accent sur l’intérêt de l’approche multicouches, plus précisément sur son efficacité et sa fiabilité pour la supervision, l’optimisation multi-objectifs et le contrôle coopératif distribué sur des systèmes complexes de transport d’eau. La première couche analysée est le réseau hydraulique composé de canaux d’écoulements à surface libre, de sous-réseaux maillés de tuyaux sous pression et des structures hydrauliques. En intégrant les équations de Saint-Venant pour décrire l’écoulement physique des fluides en surface libre et la méthode de Lattice Boltzmann pour la simulation du fluide, nous obtenons un modèle non linéaire discret pour les canaux à surface libre. Les structures hydrauliques sont généralement traitées comme des limites internes des biefs (tronçons) et modélisées par des relations entre les variables de flux et de pression.

Permettant l’échange d’informations entre les éléments du système de contrôle, le réseau de communication sera considéré comme la deuxième couche. La résolution des problèmes d’hétérogénéités des systèmes et des communications (par exemple les retards de diffusion dans le réseau, la perte de paquets, la consommation d’énergie) sera étudié en introduisant une architecture de réseau hybride avec un routage dynamique basé sur les exigences de Qualité de Service (QoS) des applications de contrôle. Pour le routage dynamique dans le réseau, une composition pondérée de certaines métriques standards est proposée afin que le protocole de routage utilisant cette métrique composite converge sans boucle avec une « route » optimum. Grâce à différents scénarios de simulation, plusieurs critères de performance du réseau ont été évalués.

La comparaison des résultats de simulation permet de valider l’intérêt de cette approche de composition pour le routage dynamique. Une troisième couche propose un système de contrôle réactif optimal développé pour la régulation du réseau d’irrigation dans un modèle étendue à grande échelle : Distributed Coopera- tive Model Predictive Control (DCMPC). Cette partie aborde la mise en œuvre de différentes stratégies de contrôle (centralisées, décentralisées et distribuées) et intègre la communication coopérative entre les contrôleurs MPC locaux afin d’améliorer les performances globales du système.
